GATES Hydraulic Hose EFG5K - SAE 100R13
Gates Extremely High Pressure Hose (SAE 100R13) Meets Flame Resistance "MSHA 2G"
SKU: EFG5K
Origin: USA
Tube: Black, oil resistant, synthetic rubber (Nitrile - Type C).
Reinforcement: 4&6 alternating layers of spiralled high-tensile steel.
Cover: Black, oil resistant, synthetic rubber (Polychloroprene - Type A), with colour coded layline.
Available: with Standard and MegaTuff® covers.
Applications: Extremely high-pressure high-impulse applications. Exceeds all requirements of ISO 18752 Grade D and SAE 100R13 and performance requirements of EN 856 4SH (-16 and -20), EN 856 4SP (-10 and -12), EN 856 R13 (-12, -16, -20, -24, -32). Compatible with biodegradable hydraulic fluids like polyolester, polyglycol and vegetable oil as well as standard petroleum-base fluids.
Temperature Range: -40°C to +121°C.
| Title | File type | Size | Download |
|---|---|---|---|
| Ống Thủy Lực GATES EFG5K | 0.47 MB | Download |
