Gates Hydraulic Hose M3K - SAE 100R17

SKU : M3K

Tube: Black, oil resistant, synthetic rubber (Nitrile - Type C).

Reinforcement: Braided, high-tensile steel wire. -4, -5, -6 and -8 sizes are one braid; -10, -12 and -16 sizes are one braid.

Cover: Black, oil, abrasion and weather resistant, synthetic rubber (Nitrile/PVC - Type C2) with colour coded layline.

Available with Standard, XtraTuff® and MegaTuff® covers.

Applications: High-pressure hydraulic oil lines, Exceeds ISO 18752 Grade B, SAE 100R17 and ISO 11237 R17 working pressure, minimum bend radius requirements and performance requirements of EN 857 1SC. M3K hose has smaller exterior dimensions and significantly tighter bend radius than other SAE 100R1 and 100R2 hose
Temperature Range: -40°C to +100°C.
